Agilent Technologies E4448A Service Guide

Chapter 10 237
Replaceable Parts Lists and Locations
Replaceable Parts
W11 Cable (3), coax, 21.4
MHz from A10 3rd
Converter J5 to
A8 Analog IF, J13
8120-5021 X X X X X X
W12 Cable (6), coax,
TRIGGER IN from rear
panel to A8 Analog IF, P4
8120-5053 X X X X X X
W13 Cable (20), coax,
TRIGGER 1 OUT to
A9 2nd LO, J12
8121-0153 X X X X X X
W14 Cable (30), coax,
TRIGGER 2 OUT to
A9 2nd LO, J11
8121-0153 X X X X X X
W15 Cable, semi-rigid, A9
2nd LO, J10 to Lowband, J5
E4440-20084 X X X X X X
W16 Cable (4), coax, 600
MHz from A11 Reference
board P3 to A9 2nd LO, J1
8120-5022 X X X X X X
W17 Cable (10), coax
(with ferrites), A19 RYTHM
highband output to A10 3rd
Converter J1
E4440-60371 X X X X X X
W18 Cable (7), coax
(with ferrites), 321.4 MHz
A20 Lowband assy to
A10 3rd Converter J2
E4440-60372 X X X X X X
W19 Cable (40), coax
321.4 MHz IF OUT from
A10 3rd Converter J4 to
rear panel
8121-0149 X X X X X
W20 Cable (50), coax, 50
MHz Cal signal from
A10 3rd Converter J7 to
A14 Attenuator
8121-0156 X X X X X X
W21 Cable (90), coax, 10
MHz Out from
A11 Reference Assy P2 to
rear panel
8120-5053 X X X X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
