Agilent Technologies E4448A Service Guide

242 Chapter 10
Replaceable Parts Lists and Locations
Replaceable Parts
W64 Cable (60), coax,
WB IF CA:L from
A31 WB Analog IF to
A10 3rd Converter J6
(Option 122 or 140)
8121-1007 X X X X X
W65 Cable (40), coax,
321.4 MHz IF from
A10 3rd Converter J4 to
A31 WB Analog IF
(Option 122 or 140)
E4440-60343 X X X X X
W66 Cable (66), coax,
321.4 MHz from
A31 WB Analog IF to
Rear Panel
(Option 122 or 140)
8121-1323 X X X X X
W67 Cable, coax, Video Out
from Digital IF J100 to Rear
Panel (Option 124)
8121-0964 X X X X X X
W68 Cable, ribbon,
SBTX Tower Control,
A29 SBTX Driver to A19
SBTX/RYTHM
E4446-60008 X X X
W69 Cable, ribbon,
20 pin, SBTX Digital
Control, A29 SBTX Driver
to A13 Front End Driver
E4446-60009 X X X
W70 Cable, ribbon,
14 pin, SBTX Power,
A29 SBTX Driver to
A13 Front End Driver
E4446-60010 X X X
W71 Cable, ribbon,
FELOMA, A29 SBTX Driver
to A21 FELOMA
E4446-60011 X X X
W75 Cable (41), coax,
70 MHz IF OUT, from A33
Option card J2 to rear panel
(Option H70)
8121-0705 X X X X X X
W76 Cable (40), coax,
321.4 MHz IF IN, from A10
3
rd
Converter J4 to A33
Option card J1 (Option H70)
8121-0704 X X X X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
