Chapter 10 243
Replaceable Parts Lists and Locations
Replaceable Parts
W77 Cable (51), coax,
321.4 MHz IF OUT, from
A33 Option card J5 to rear
panel (Option H70)
8121-0705 X X X X X X
W78 Cable, semi-rigid,
FL2 to FL3
(Option 122 or 140)
E4446-20047 X X X X X
W79 Cable, semi-rigid,
FL3 to A20 Lowband
(Option 122 or 140)
E4446-20048 X X X X X
W80 Cable, semi-rigid,
Input Attenuator to
Switch 1 (Option 123)
E4440-20090 X X X
W81 Cable, semi-rigid
(with ferrites),
Switch 1 (bottom switch)
port 2 to RYTHM input
(Option 123)
E4440-20091 X X X
W82 Cable, semi-rigid,
Switch 1 (bottom switch)
port 1 to Mixer input
(Option 123)
E4440-20092 X X X
W83 Cable, semi-rigid,
Mixer LO IN to cable W88
from SLODA LO Out
(Option 123)
E4440-20093 X X X
W84 Cable (1), coax,
Dual Mixer Out to Switch 2
(top switch) port 1
(Option 123)
E4440-60298 X X X
W85 Wire Harness,
FE Driver J11 to
Switches/Mixer
(Option 123)
E4440-60077 X X X
W86 Cable (10), coax,
3rd Converter J1 to
Switch 2 (top switch) port C
(Option 123)
E4440-60373 X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
