Agilent Technologies E4448A Service Guide

244 Chapter 10
Replaceable Parts Lists and Locations
Replaceable Parts
W87 Cable (2), coax,
RYTHM t o
Switch 2 (top switch) port 2
(Option 123)
E4440-60373 X X X
W88 Cable, semi-rigid,
SLODA LO Out to cable
W83 Mixer LO In
(Option 123)
E4440-20087 X X X
W89, Cable, coax,
Switch 3 bottom port to
RHYTHM/SBTX
(Option 123)
E4440-60373 X X X
W90 Cable, Flat Flex,
Unpreselected mixer to
mixer bias board
(Option 123)
8150-5698 X X X
W91, Cable, ribbon,
Switch Control, Option
Driver Assy J3 to SW4
(top switch)
(Option 110)
E4440-60455 X X X
W92, Cable, ribbon,
Switch Control
Option Driver Assy J8 to
SW5 (bottom switch)
(Option 123)
E4440-60455 X X X
W93, Cable, coax,
Unpreselected mixer to
Switch 3 coax switch top
port (Option 123)
E4440-60298 X X X
W94, Cable, coax,
SW3 coax switch center
connector to 3rd Converter
(Option 123)
E4440-60373 X X X
W95, Cable, ribbon,
Mixer Bias board control.
Option Driver Assy J7 to
Mixer Bias Board
(Option 123)
E4440-60397 X X X
W96, Cable, ribbon,
Driver board J9 to coax
switch (Option 123)
E4440-60427 X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
