Agilent Technologies E4448A Service Guide

246 Chapter 10
Replaceable Parts Lists and Locations
Replaceable Parts
W107, Cable, semi-rigid,
Switch 4 port 4 to W34 cable
to RHYTHM/SBTX
(Option 110, for instruments
that do not have Opt 123)
E4446-20072 X X X
W108, Cable, coax,
Front Panel Audio In to
Audio Board Assy
(Option 107)
8121-1432 X X X X X X
W109, Cable semi-rigid
A15 Attenuator to Switch 6
(Option 110 or
Option 110 with Option 123
E4440-20315 X X X
W110, Cable, semi-rigid,
Switch 6 to RHYTHM
(when Option 110 is
installed and Option 123 is
not)
E4440-20316 X X X
W111, Cable, semi-rigid,
Switch 6 to Option 123
Switch 1 Center Port
(Opt 110 with Option 123)
E4440-20317 X X X
W112, Cable, semi-rigid,
Preamp Out from Switch 6
(Option 110)
E4440-20323 X X X
W113, Cable, semi-rigid,
Preamp In from Switch 6
(Option 110)
E4440-20304 X X X
W114, Cable, ribbon,
Switch Control,
Option Driver Assy to SW 6
for Option 110
E4440-60427 X X X
W115, Cable, semi-rigid,
FL4 to A34 (Option 110 +
123 combination)
E4440-20324 X X X
a. The numbered clip sleeves are not included with the cables. Order mechanical
part 7121-8265 to replace the clips.
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
