Agilent Technologies E4448A Service Guide

Chapter 10 247
Replaceable Parts Lists and Locations
Replaceable Parts
Table 10-4 Front Panel Connectors and Mounting Hardware
Description Part Number E4440A E4443A E4445A E4446A E4447A E4448A
J1 Input Connector,
Type N
08559-60002 X X X
Bracket, Type N Input E4440-20185 X X X
Input Connector Nut,
Type N Input
2950-0132 X X X
Input Connector
Washer, Type N Input
2190-0104 X X X
J1 Input Connector,
3.5 mm (m) (Option
BAB)
08673-60040 X
Bracket, 3.5 mm Input
(Option BAB)
E4440-20094 X
Input Connector Nut,
3.5 mm (Option BAB)
2950-0001 X
Input Connector
Washer, 3.5 mm
(Option BAB)
2190-0016 X
J1 Input Connector,
2.4 mm
5064-3970 X X X
Bracket, 2.4 mm
RF Input
E4446-20004 X X X
Input Connector Nut,
2.4 mm
0590-2563 X X X
Ext Trigger − Front
Panel (part of W1)
E4406-60139 X X X X X X
Probe Power
Part of A2 Front Panel
Interface Assy
1252-7437 X X X X X X
IF INPUT connector
SMA (Option AYZ)
1250-1666 X X X X
1
st
LO OUT connector
SMA (Option AYZ)
1250-1666 X X X X
Nut, 1/4 - 36,
LO OUT or IF INPUT
(Option AYZ)
2950-0223 X X X X
Nut, hex 15/32-32 for
External Trigger IN
and Audio IN
2950-0035 X X X X X X
