10 Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide
Measurement Trend 95
Chart Logic Bus Timing 96
Chart Logic Bus State 97
5 Reference Waveforms
To save a waveform to a reference waveform location 99
To display a reference waveform 100
To scale and position reference waveforms 101
To adjust reference waveform skew 101
To display reference waveform information 102
To save/recall reference waveform files to/from a USB storage
device 102
6 Digital Channels
To connect the digital probes to the device under test 103
Probe cable for digital channels 104
Acquiring waveforms using the digital channels 107
To display digital channels using AutoScale 107
Interpreting the digital waveform display 108
To change the displayed size of the digital channels 109
To switch a single channel on or off 110
To switch all digital channels on or off 110
To switch groups of channels on or off 110
To change the logic threshold for digital channels 110
To reposition a digital channel 111
To display digital channels as a bus 112
