Agilent Technologies InfiniiVision 3000 MSO-X 3012A User Manual

218 Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide
14 Measurements
You can also configure the [Quick Action] key to display the Snapshot All
popup. See "Configuring the [Quick Action] Key" on page 298.
Voltage Measurements
The following figure shows the voltage measurement points.
Measurement units for each input channel can be set to Volts or Amps
using the channel Probe Units softkey. See "To specify the channel units" on
page 67.
The units of math waveforms are described in "Units for Math
Waveforms" on page 74.
• "Peak-Peak" on page 219
Amplitude
Maximum
Minimum
Base
Top
Peak-Peak
