Measurements 14
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 217
Note that additional Power App measurements are available when the
DSOX3PWR power measurement and analysis license is installed and the
Power Application is enabled. For more information, see the DSOX3PWR
Power Measurement Application User's Guide at
"www.agilent.com/find/3000X- Series- manual" or on the Documentation CD.
Snapshot All
The Snapshot All measurement type displays a popup containing a
snapshot of all the single waveform measurements.
"Phase" on page 230 Measures between two sources.
Press Settings to specify the
second source.
"Preshoot" on page 222
"Ratio" on page 225 Measures between two sources.
Press Settings to specify the
second source.
"Rise Time" on page 229
"DC RMS" on page 223
"AC RMS" on page 223
"Top" on page 219
"+ Width" on page 228 Yes
"– Width" on page 228 Yes
"X at Max Y" on page 232 Yes The resultant units are in Hertz.
"X at Min Y" on page 231 Yes The resultant units are in Hertz.
*
Use the cursors to make other measurements on FFT.
Measurement Valid
for
Math
FFT
*
Valid for
Digital
Channels
Notes
