Web Interface 20
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 305
Simple Remote Front Panel
To operate the oscilloscope using the web interface's Simple Remote Front
Panel:
1 Access the oscilloscope's web interface (see "Accessing the Web
Interface" on page 302).
2 When the oscilloscope's web interface is displayed, select
Browser Web Control, then select Simple Remote Front Panel. After a few
seconds the Remote Front Panel appears.
3 Use the Main Menu and the Function Keys to control the oscilloscope.
To view Quick Help, right- click on a softkey.
Scrolling and
Monitor
Resolution
When using a monitor resolution of 800 x 600 or less on the remote
computer, you need to scroll to access the full remote front panel. To
display the remote front panel without scroll bars, use a monitor
resolution greater than 800 x 600 on your computer's display.
Main Menu
Function Keys
Hint appears
when you roll
over with
mouse
Softkeys
(left-click to
select, right-click
for Quick Help)
