I2C/SPI Triggering and Serial Decode 24
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 375
The Set all Bits softkey will set all bits in the data string to the value of
the 0 1 X softkey.
SPI Serial Decode
To set up the oscilloscope to capture SPI signals, see "Setup for SPI
Signals" on page 370.
To set up SPI serial decode:
1 Press [Serial] to display the Serial Decode Menu.
NOTE
For SPI decode information see "SPI Serial Decode" on page 375.
NOTE
For SPI triggering setup see "SPI Triggering" on page 373.
