394 Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide
26 MIL-STD-1553/ARINC 429 Triggering and Serial Decode
• The 0 1 X softkey lets you set the bit time position value as a 1, 0,
or X (don't care).
• Parity Error — triggers if the (odd) parity bit is incorrect for the data
in the word.
• Sync Error — triggers if an invalid Sync pulse is found.
• Manchester Error — triggers if a Manchester encoding error is detected.
MIL-STD-1553 Serial Decode
To set up the oscilloscope to capture MIL- STD-1553 signals, see "Setup for
MIL- STD- 1553 Signals" on page 391.
To set up MIL- STD-1553 serial decode:
1 Press [Serial] to display the Serial Decode Menu.
2 Use the Base softkey to select between hexadecimal and binary display
of the decoded data.
The base setting is used for the display of the remote terminal address
and the data, in both the decode line and in the Lister.
3 If the decode line does not appear on the display, press the [Serial] key
to turn it on.
4 If the oscilloscope is stopped, press the [Run/Stop] key to acquire and
decode data.
For MIL-STD-1553 decode information see "MIL-STD-1553 Serial Decode" on page 394.
For MIL-STD-1553 triggering setup see "MIL-STD-1553 Triggering" on page 393.
