Waveform Generator 16
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 259
The source waveform is decimated into 8192 (maximum) or fewer
arbitrary waveform points.
To output the waveform generator sync pulse
1 If the Waveform Generator Menu is not currently displayed on the
oscilloscope's softkeys, press the [Wave Gen] key.
2 In the Waveform Generator Menu, press the Settings softkey.
3 In the Waveform Generator Settings Menu, press the Trig Out softkey and
turn the Entry knob to select Waveform Generator Sync Pulse.
To specify the expected output load
1 If the Waveform Generator Menu is not currently displayed on the
oscilloscope's softkeys, press the [Wave Gen] key.
When you create a new arbitrary waveform, the existing arbitrary waveform definition
is overwritten. Note that you can use the [Save/Recall] key and menu to save
arbitrary waveforms to one of four internal storage locations or to a USB storage
device, and you can recall them later. See "To save arbitrary waveforms" on page 272
and "To recall arbitrary waveforms" on page 275.
If the source waveform frequency and/or voltage exceed the capabilities of the waveform
generator, the arbitrary waveform will be limited to the capabilities of the waveform
generator. For example, a 20 MHz waveform captured as the arbitrary waveform, becomes a
12 MHz waveform.
Waveform Type Sync Signal Characteristics
All waveforms except
DC, Noise, and
Cardiac
The Sync signal is a TTL positive pulse that occurs when the waveform
rises above zero volts (or the DC offset value).
DC, Noise, and
Cardiac
N/A
