Reference 21
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 319
Passive Probes
All InfiniiVision oscilloscopes recognize passive probes such as the
N2862A/B, N2863A/B, N2889A, N2890A, 10073C, 10074C, and 1165A.
These probes have a pin on their connector that connects to the ring
around the oscilloscope's BNC connector. Therefore, the oscilloscope will
automatically set the attenuation factor for recognized Agilent passive
probes.
Passive probes that do not have a pin that connects to the ring around
the BNC connector will not be recognized by the oscilloscope, and you
must set the probe attenuation factor manually. See "To specify the probe
attenuation" on page 67.
The following passive probes can be used with the InfiniiVision
3000 X-Series oscilloscopes. Any combination of passive probes can be
used.
Single-Ended Active Probes
The following single- ended active probes can be used with the
InfiniiVision 3000 X- Series oscilloscopes.
Table 6 Passive Probes
Model Description
1165A Passive probe, 10:1, 600 MHz, 1.5 m
10070C/D Passive probe, 1:1 20 MHz, 1.5 m
10073C Passive probe, 10:1, 500 MHz, 1.5 m
10074C Passive probe, 10:1, 150 MHz, 1.5 m
10076A/B Passive probe, 100:1, 4 kV, 250 MHz
N2771A/B Passive probe, 1000:1, 30 kV, 50 MHz
N2862A/B Passive probe, 10:1, 150 MHz, 1.2 m
N2863A/B Passive probe, 10:1, 300 MHz, 1.2 m
N2889A Passive probe, 10:1/1:1, 350 MHz, 1.2 m
N2890A Passive probe, 10:1, 500 MHz, 1.2 m
