Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 5
In This Guide
This guide shows how to use the InfiniiVision 3000 X-Series oscilloscopes.
When unpacking and using the
oscilloscope for the first time, see:
• Chapter 1, “Getting Started,” starting on page 23
When displaying waveforms and
acquired data, see:
• Chapter 2, “Horizontal Controls,” starting on page 47
• Chapter 3, “Vertical Controls,” starting on page 61
• Chapter 4, “Math Waveforms,” starting on page 71
• Chapter 5, “Reference Waveforms,” starting on page
99
• Chapter 6, “Digital Channels,” starting on page 103
• Chapter 7, “Serial Decode,” starting on page 123
• Chapter 8, “Display Settings,” starting on page 129
• Chapter 9, “Labels,” starting on page 135
When setting up triggers or changing
how data is acquired, see:
• Chapter 10, “Triggers,” starting on page 141
• Chapter 11, “Trigger Mode/Coupling,” starting on
page 177
• Chapter 12, “Acquisition Control,” starting on page 185
Making measurements and analyzing
data:
• Chapter 13, “Cursors,” starting on page 203
• Chapter 14, “Measurements,” starting on page 213
• Chapter 15, “Mask Testing,” starting on page 239
When using the built-in license
enabled waveform generator, see:
• Chapter 16, “Waveform Generator,” starting on page
251
When saving, recalling, or printing,
see:
• Chapter 17, “Save/Recall (Setups, Screens, Data),”
starting on page 263
• Chapter 18, “Print (Screens),” starting on page 279
When using the oscilloscope's utility
functions or web interface, see:
• Chapter 19, “Utility Settings,” starting on page 283
• Chapter 20, “Web Interface,” starting on page 301
