216 Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide
14 Measurements
Measurement Valid
for
Math
FFT
*
Valid for
Digital
Channels
Notes
"Snapshot All" on page 217
"Amplitude" on page 219
"Area" on page 233
"Average" on page 222 Yes, Full
Screen
"Base" on page 220
"Burst Width" on page 228
"Counter" on page 227 Yes Not valid for math waveforms.
"Delay" on page 229 Measures between two sources.
Press Settings to specify the
second source.
"Duty Cycle" on page 228 Yes
"Fall Time" on page 229
"Frequency" on page 226 Yes
"Maximum" on page 219 Yes
"Minimum" on page 219 Yes
"Rising Edge Count" on
page 233
"Falling Edges Count" on
page 233
"Positive Pulse Count" on
page 232
"Negative Pulse Count" on
page 233
"Overshoot" on page 221
"Peak-Peak" on page 219 Yes
"Period" on page 226 Yes
