9 If you select a line # mode, press the Line # softkey, then rotate the
Entry knob to select the line number on which you want to trigger.
The following table lists the line (or count) numbers per field for each
video standard.
The following table lists the line numbers for each EDTV/HDTV video
standard (available with the DSOX3VID extended video triggering
license).
Video Triggering
Examples
The following are exercises to familiarize you with video triggering. These
exercises use the NTSC video standard.
• "To trigger on a specific line of video" on page 166
• "To trigger on all sync pulses" on page 168
• "To trigger on a specific field of the video signal" on page 168
• "To trigger on all fields of the video signal" on page 169
• "To trigger on odd or even fields" on page 170
Video standard Field 1 Field 2 Alt Field
NTSC 1 to 263 1 to 262 1 to 262
PAL 1 to 313 314 to 625 1 to 312
PAL-M 1 to 263 264 to 525 1 to 262
SECAM 1 to 313 314 to 625 1 to 312
EDTV 480p/60 1 to 525
EDTV 567p/50 1 to 625
HDTV 720p/50, 720p/60 1 to 750
HDTV 1080p/24, 1080p/25, 1080p/30,
1080p/50, 1080p/60
1 to 1125
HDTV 1080i/50, 1080i/60 1 to 1125
