100 Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide
5 Reference Waveforms
2 In the Reference Waveform Menu, press the Ref softkey and turn the
Entry knob to select the desired reference waveform location.
3 Press the Source softkey and turn the Entry knob to select the source
waveform.
4 Press the Save to R1/R2 softkey to save the waveform to the reference
waveform location.
To clear a
reference
waveform
location
1 Press the [Ref] key to turn on reference waveforms.
2 In the Reference Waveform Menu, press the Ref softkey and turn the
Entry knob to select the desired reference waveform location.
3 Press the Clear R1/R2 softkey to clear the reference waveform location.
Reference waveforms are also cleared by a Factory Default or Secure
Erase (see Chapter 17, “Save/Recall (Setups, Screens, Data),” starting on
page 263).
To display a reference waveform
1 Press the [Ref] key to turn on reference waveforms.
2 In the Reference Waveform Menu, press the Ref softkey and turn the
Entry knob to select the desired reference waveform location.
3 Then, press the Ref softkey again to enable/disable the reference
waveform display.
NOTE
Reference waveforms are non-volatile — they remain after power cycling or performing a
default setup.
