Getting Started 1
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 43
Learn the Oscilloscope Display
The oscilloscope display contains acquired waveforms, setup information,
measurement results, and the softkey definitions.
4. TRIG OUT
connector
Trigger output BNC connector. See “Setting the Rear Panel TRIG OUT
Source" on page 292.
5. Calibration
protect button
See “To perform user calibration" on page 294.
6. EXT TRIG IN
connector
External trigger input BNC connector. See “External Trigger Input" on
page 182 for an explanation of this feature.
7. USB Host port This port functions identically to the USB host port on the front panel.
USB Host Port is used for saving data from the oscilloscope and loading
software updates. See also USB Host port (see page 40).
8. USB Device
port
This port is for connecting the oscilloscope to a host PC. You can issue
remote commands from a host PC to the oscilloscope via the USB device
port. See “Remote Programming with Agilent IO Libraries" on page 307.
