Current Probes
The following current probes can be used with the InfiniiVision
3000 X-Series oscilloscopes.
N2790A High-voltage differential probe, 50:1 or 500:1 (switchable), 100 MHz with
AutoProbe interface
4
N2791A High-voltage differential probe, 25 MHz, +/-700 V, 1 MOhm termination,
10:1 or 100:1 (switchable)
N2792A Differential probe, 200 MHz 10:1, 50 Ohm termination
N2793A Differential probe, 800 MHz 10:1, +/-15 V, 50 Ohm termination
N2891A 70 MHz, 7 kV high-voltage differential probe
1
See "AutoProbe Interface" on page 318.
Table 8 Differential Probes (continued)
Model Description Quantity
Supported
1
Table 9 Current Probes
Model Description Quantity
Supported
1
1146A Current probe, 100 kHz, 100 A, AC/DC
1147A Current probe, 50 MHz, 15 A, AC/DC with AutoProbe interface 2
N2774A (Obsolete, replaced by N2782A) with N2775A power supply
N2780A Current probe, 2 MHz, 500 A, AC/DC (use with N2779A power supply)
N2781A Current probe, 10 MHz, 150 A, AC/DC (use with N2779A power supply)
N2782A Current probe, 50 MHz, 30 A, AC/DC (use with N2779A power supply)
N2783A Current probe, 100 MHz, 30 A, AC/DC (use with N2779A power supply)
N2893A Current probe, 100 MHz, 15 A, AC/DC with AutoProbe interface 2
1
See "AutoProbe Interface" on page 318.
