Setting the 8-bit Configuration Switch (On-Board LAN)
One start bit and one stop bit are always used (not selectable).
Per default, the module will turn into 19200 baud, 8 data bit with no parity.
Tab le 7 Baudrate Settings (without on-board LAN)
Switches Baud Rate Switches Baud Rate
345 345
0 0 0 9600 1 0 0 9600
0 0 1 1200 1 0 1 14400
0 1 0 2400 1 1 0 19200
0 1 1 4800 1 1 1 38400
Tab le 8 Data Bit Settings (without on-board LAN)
Switch 6 Data Word Size
0 7 Bit Communication
1 8 Bit Communication
Tab le 9 Parity Settings (without on-board LAN)
Switches Parity
78
0 0 No Parity
1 0 Odd Parity
11 Even Parity
