Agilent Technologies PL-GPC 220

PL-GPC 220 User Manual 17
Introduction to PL-GPC 220
1
System Description and General Operation
Injection Sequence
1 Default condition prior to injection:
• Injection valve in the Inject position
• Vial in carousel
• Syringe at mid point
2 Sample loaded
• Valve switched to load position
• Vial lifted to needle
• Syringe sucks 800 μL from the vial to fill the loop and partially fills the
overflow loop
=di
8daY
8dajbch
Ejbe
=di
8daY
8dajbch
Ejbe
