Agilent Technologies PL-GPC 220 User Manual

30 PL-GPC 220 User Manual
4 Using the Module
The Graphical User Interface
The Graphical User Interface
A Windows-based Graphical User Interface (GUI) providing total instrument
control is used to operate the PL-GPC 220. An intuitive single control panel
provides simplistic control as well as a comprehensive monitoring system. The
instrument status can be rapidly assessed for each of the instrument’s
modules.
Figure 9 Graphical User Interface
NOTE
Onscreen help, accessed directly from the software control, provides an interactive guide to
the operation of the instrument and should be used in addition to this manual.
IddaWVg
Ejbe;adl8dcigda
G>9ZiZXidg
BdYZhd[DeZgVi^dc
6jidhVbeaZg
6jidhVbeaZg8dc[^\jgVi^dc:Y^idg
G>8dc[^\jgVi^dc:Y^idg
DkZc8dc[^\jgVi^dc:Y^idg
Ejbe8dc[^\jgVi^dc:Y^idg
