PL-GPC 220 User Manual 23
Site Requirements and Specifications
2
Physical Specifications
Physical Specifications
Tab le 1 Physical Specifications PL-GPC 220
Type Specification Comments
Line voltage 230 V AC (±10 %) Single phase with earth
Power consumption 3300 VA, 2310 W/7900 BTU
Line frequency 50 or 60 Hz (±5 %)
Size (width × depth × height) 1400 mm x 560 mm x 630 mm
Packaged Size (width × depth
× height)
930 mm x 760 mm x 860 mm Two boxes
Weight 180 kg (396 lbs)
Ambient operating
temperature
15 – 35 ° C (59 – 95 ° F) At constant temperature
Ambient non-operating
temperature
-40 – 70 ° C (-4 – 158 ° F)
Operating altitude Up to 2000 m (6562 ft)
Non-operating altitude Up to 4600 m (15091 ft)
Humidity <80 % at 25 – 35 °C
Safety standards IEC
