PL-GPC 220 User Manual 27
Unpacking the Instrument
3
Unpacking the Instrument
Unpacking the Instrument
The instrument is shipped on a specialized pallet inside a wooden carton.
The main oven unit will be found in one of the boxes and the solvent
delivery system and accessories in the second box. Unpack as follows:
1 Remove the screws (Phillips screws, typically 3 per side) around the top
edge of the carton, securing the lid in position. Lift off the lid.
2 Lift and remove the sheet of foam beneath the lidpackaging which protects
the top of the unit.
The top of the unit is revealed.
3 Remove the five sections of foam packaging surrounding the unit: one at
each side, one piece at the front and two small sections behind the unit. The
wires are tucked down between the two foam sections at the back.
Tools required Description
Phillips screwdriver (medium)
Flat screwdriver (medium)
Very heavy weight
The instrument weighs 185 kg (408 lbs).
➔ Lift the main oven assembly with at least four persons.
➔ Lift the solvent delivery unit with at least two persons.
➔ Refer to local statutory Manual Lifting Regulations & Guidelines.
Condensation in the instrument
The electrical safety of the instrument cannot be guaranteed until it has dried out.
➔ Leave the instrument standing in a warm, dry, ventilated environment for 1 h to let
condensation evaporate.
➔ Do not connect any electrical power until this period has expired.
