162
Settings and Adjustments
Station programming
4
Station Programming
Connect to the same network as the Door Station and manage the settings from PC web browser.
System requirements
The programming PC must meet the following requirements to proceed.
Connecting to a PC
Using a Cat5e/6 "Straight-Through" cable, connect the station and PC to the same PoE switch or injector.
Use CAT5e/6 straight cable to connect the devices through LAN port.
Login to this station
1. Start the PC and open one of the before mentioned web browsers.
2. Enter the address below into the web browser address bar.
IPv4 example - https://IP address of this device/webset.cgi?login
IPv6 example - https://[IP address of this device]/webset.cgi?login
• If a certificate error window is displayed, click [Go on to the webpage]. To prevent it from appearing, the
administrator will need to disable it. Contact your system administrator.
• Language selection window will be displayed.
Network Ethernet (10BASE-T, 100BASE-TX)
Web browser Microsoft Edge / Internet Explorer 10.0, 11.0 / Mozilla Firefox 59 or 60 (TLS1.0, 1.1, or 1.2
enabled)
Station
RJ45
RJ45
CAT5e/6 straight cable
CAT5e/6 straight cable
RJ45
RJ45
PC
PoE compatible
switch
To Next Page
