Aiphone IX SERIES User Manual

128
Settings and Adjustments
Configuring on the station
4
Record Settings
Configure settings related to video/audio recording. If there is no image, only audio will be recorded. When recording
audio during a call, audio of this station will also be recorded.
1. Tap [Record] on the Settings (1/2) screen.
• The Record Settings screen will be shown.
2. Configure the settings.
Important
• Video/audio cannot be recorded even if configured if no microSD card is inserted. Refer to “About microSD card (→page 27)”
for details.

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
