Page #226 background imageLoading...
Page #226 background image
226
Other
Appendix
5
Specifications
Maintenance
Clean the station gently with a soft, dry cloth. For difficult stains, dip a soft cloth in neutral detergent diluted with
water, wring it out well, and then clean unit.
Use a soft, dry cloth (for use in wiping mirrors) when wiping the display.
Power PoE (IEEE802.3af Class 0 standard)
Current Consumption Standby: 66 mA; Maximum: 155 mA
Communication Hands-free/touch-to-talk
(concurrent communication for calls between handsets only)
Display 7" TFT LCD display WVGA 800×480 (approx. 1.15 million pixels)
Camera 1/4-type CMOS VGA 640×480 (approx. 300,000 pixels)
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Audio codec G.711 (u-law, A-law), G.722
Video codec H.264/AVC, Motion-JPEG
Protocol IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP, SFTP,
DHCP, NTP, DNS
Encryption system TLS1.0, TLS1.1, TLS1.2
Packet transmission system Unicast and multicast
Number of stations in
address book
500 stations
Operating temperature 0 °C to +40 °C (+32 °F to +104 °F)
Mounting Table/wall-mounted
Materials Fire-retardant resin
Color IX-MV7-HW, IX-MV7-W: White
IX-MV7-HB, IX-MV7-B: Black
Dimensions IX-MV7-HB and IX-MV7-HW: 280 mm (11") [W] × 204 mm (8-1/16") [H] × 55.5 mm (2-3/16") [D]
IX-MV7-B and IX-MV7-W: 220 mm (8-11/16") [W] × 172 mm (6-3/4") [H] × 31.5 mm (1-1/4") [D]
(excluding projection)
Weight IX-MV7-HB and IX-MV7-HW: Approx. 1.0 kg (2.2 lbs) (approx. 1.3 kg (2.9 lbs) when used on
table)
IX-MV7-B and IX-MV7-W: Approx. 680 g (1.5 lbs) (approx. 870 g (1.97 lbs) when used on table)
Important
Do not use chemicals such as benzene or paint thinner. You may damage the surface of the station, or cause discoloration.
