Aiphone IX SERIES User Manual

28
Before Using
About microSD card
2
Inserting/Removing microSD Cards
Inserting the microSD card
1. Press the Home button or tap the
standby screen to display the
Home Screen.
2. Open the microSD card slot cover.
3. Insert the microSD card straight
into the slot and close the cover.
• will be displayed on the screen once the
microSD card is recognized (mounted), and
the microSD card will be available to use.
will not be displayed if the microSD card is
not recognized.
Removing the microSD card
1. Tap .
2. Tap [Yes].
• disappears from the screen when the
microSD card has been removed.
3. Once disappears from the
Home Screen, open the microSD
card slot cover, and push the
microSD card to remove it.

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
