Aiphone IX SERIES User Manual

24
Before Using
Answering a call
2
Using the headset
A 3rd party headset can be connected to the 3.5 mm 4-
pole stereo mini jack on this station. When using the
headset, the microphone and the speaker on the station
cannot be used. The system administrator will need to
configure the device to use a headset.
1. When receiving a call, tap .
2. Speak with the other party
3. When the communication ends,
tap .
Note
• Picking up the handset while on a call using a headset will
switch the call to the handset.

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
