Aiphone IX SERIES User Manual

83
How to use
Checking the System
3
Reviewing an error
1. Tap [Status] on the Home screen.
2. Tap [Line Supervision Results].
3. Check the station that has a
network communication error.
4. Resolve the error and perform line
monitoring again.
• If the error has been resolved, [Status] on the
Home screen will change back from red to
green.
Line Supervision start time
Station that has a network communication error.
Note
• Errors will be detected even if the network itself is healthy
and there is a malfunction in the other station.

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
