FILLING OF OIL RESERVOIR
... liters of oil with the specifications of ISO HV/46 (codes of various brands of oil are shown
in this page) … shall be added for this operation.
a) Open the side cover next to the reducer.
b) You can add hydraulic oil from the filler opening on the reservoir.
Use external filter to prevent mixing of foreign material to the oil as shown below in order to
transfer the oil to the reservoir from the container.
c) Check the oil level from the inspection window in reservoir.
-Close the cover when you are done.
