1) Place the material between rolls.
2) Place the material in parallel to the axis of rolls.
Side rolls may be used for facilitating this operation. Evenness can be achieved by lifting the
side rolls and leaning the material to be bent to the rolls.
BENDING OPERATIONS
First step is powering the machine. Steps are as follows.
1) Bring the switch on power panel to position 1.
2) Bring the switch on control panel to position 1.
3) Ensure that the power light is illuminated. If it is not illuminated, check the safety rope
and the emergency stop button.
4) Press the start button.
Your machine is ready for operation. You may bend the material according to the steps that
will be described below.
OPERATION STAGES
When you operate the machine in rapid mode, you will observe that upper and lower rolls
rotate together. When you operate the machine in slow mode, lower ROLL rotates only. If
you compress lower roll, lower roll and upper roll contact each other and rotate together.
Pressure moves in the easiest direction as per the logic of hydraulics. Therefore, resistance
shall be equal so that the rotating speed of the upper and lower rolls will be equal.
When the rolls are detached, endurance control system operates according to the pumping
capacity. Due to the low efficiency of hydraulic pump, only the lower rolls rotate. This would
not affect the bending capacity.
