User Guide V1.1.0 Issue 1
RECORD / Stereo
Stereo recording/playback to/from a connected USB drive.
 USB-A audio/data and SD recording/playback features utilise the same system
resources and cannot be used at the same time.
Stereo Record
The top section of the screen includes level meters for the channels being
recorded, recording controls and information (when recording).
 Choose the channels assigned to Stereo L/R for recording in the CONFIG /
USB/SD/BT (symbols) / USB/SD screen.
Press the Record button to start recording.
Press the Stop button to stop recording.
Refer to the information box for details such as recording time, remaining time
available, and errors (periods of unrecorded data) during the recording.
Stereo recordings are stored in the AHCQ\USBREC folder on the drive.

ALLEN & HEATH CQ-12T Specifications

General

Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Frequency range	20 - 20000 Hz
Channels quantity	12 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Built-in display	Yes
Output impedance	75 Ω
Compatible memory cards	SD
XLR out	2
RJ-45 ports quantity	1
Number of microphone inputs	10
DJ mixer	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	291 mm
Height	89 mm
Weight	2400 g
Package depth	305 mm
Package width	370 mm
Package height	190 mm
Package weight	3200 g
