ALLEN & HEATH CQ-12T User Manual

 33
User Guide V1.1.0 Issue 1
Convert a Quick Channel to a Complete Channel
Any Quick Channel can be converted to a Complete Channel at any time without
any change to the audio.
This allows Quick Channels to be used for a fast setup, but which can then be
switched to Complete Channels for control of individual parameters if desired.
Open the dropdown menu from the top right-hand corner when in a bank view with
the Quick Channel selected, or when viewing the Quick Channel controls of the
channel to be converted, then select Convert.
A pop-up explaining what will happen will appear and give the option to apply or
cancel conversion.
Note that it is not possible for Complete Channels to be converted to Quick
Channels.

ALLEN & HEATH CQ-12T Specifications

General

Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Frequency range	20 - 20000 Hz
Channels quantity	12 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Built-in display	Yes
Output impedance	75 Ω
Compatible memory cards	SD
XLR out	2
RJ-45 ports quantity	1
Number of microphone inputs	10
DJ mixer	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	291 mm
Height	89 mm
Weight	2400 g
Package depth	305 mm
Package width	370 mm
Package height	190 mm
Package weight	3200 g
