ALLEN & HEATH CQ-12T User Manual

 17
User Guide V1.1.0 Issue 1
Connect using WiFi Access Point (CQ-18T, CQ-20B)
1) Navigate to CONFIG / CONTROL & NETWORK / Network
 If there is already a connection to the CQ-20B, otherwise follow First connection to a
CQ-20B.
2) Switch Enabled Network to WiFi Access Point
3) Setup the network. Recommended settings are:
• WPA2 Password on
• WPA2 Password set (change from default ‘DefaultPassword’)
• Frequency dependent on environment and other equipment
• Channel set to Auto
• SSID Hidden (once all devices have connected and stored network
details)
4) Note the network name and password.
5) Apply any changes.
6) Connect the remote device to the Wi-Fi network that’s just been set up.
7) Run CQ-MixPad or CQ4You and connect to the CQ from the Choose Unit
list.
 If the unit does not appear in the choose unit list, try selecting ‘Other’ and entering
the IP address manually. The current IP address of the unit is listed in the HOME /
SYSTEM / Info screen.

ALLEN & HEATH CQ-12T Specifications

General

Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Frequency range	20 - 20000 Hz
Channels quantity	12 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Built-in display	Yes
Output impedance	75 Ω
Compatible memory cards	SD
XLR out	2
RJ-45 ports quantity	1
Number of microphone inputs	10
DJ mixer	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	291 mm
Height	89 mm
Weight	2400 g
Package depth	305 mm
Package width	370 mm
Package height	190 mm
Package weight	3200 g
