ALLEN & HEATH CQ-12T User Manual

 35
User Guide V1.1.0 Issue 1
7.
Gain Assistant will automatically raise the Gain and
set the optimum input level.
8.
Once the Auto Set function is complete, the Auto
Gain feature will be enabled. The input is now ready
for processing and recording or adding to a mix.
 Gain Assistant can also be found in the PROCESSING / Preamp section of a
Complete Channel.
Auto Gain
This can be used independently of Auto Set and turned on or off at any time. Auto
Gain constantly checks the input signal level in the background and if the preamp
gain is set too high (e.g. an instrument or voice get louder than they were during
sound check), it will reduce gain until the signal is back to an optimum level.
Multi Select
Use Gain Assistant functions on multiple preamps at the same time with Multi
Select by simply turning it on and then selecting the desired channels; Input
Source and Gain Assistant settings will then be available at the bottom of the
screen.

ALLEN & HEATH CQ-12T Specifications

General

Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Frequency range	20 - 20000 Hz
Channels quantity	12 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Built-in display	Yes
Output impedance	75 Ω
Compatible memory cards	SD
XLR out	2
RJ-45 ports quantity	1
Number of microphone inputs	10
DJ mixer	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	291 mm
Height	89 mm
Weight	2400 g
Package depth	305 mm
Package width	370 mm
Package height	190 mm
Package weight	3200 g
