ALLEN & HEATH CQ-12T User Manual

 44
User Guide V1.1.0 Issue 1
9.
Gently raise the Output level fader to the right of
the graph and controls.
As the output level increases, feedback will occur
and the FBA will be able to detect it and add fixed
filters.
Raise the fader to a higher level that it will be used
at during the show or event to generate and detect
as much potential feedback as possible and allow
for changes to the mix (e.g. extra vocal being added
later).
When all frequencies have been detected or all 12
Fixed filters have been used, lower the level again.
10.
With setup detection complete, either engage
HOLD or switch filter Mode to Live.
 Repeat for any other outputs as required.

ALLEN & HEATH CQ-12T Specifications

General

Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Frequency range	20 - 20000 Hz
Channels quantity	12 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Built-in display	Yes
Output impedance	75 Ω
Compatible memory cards	SD
XLR out	2
RJ-45 ports quantity	1
Number of microphone inputs	10
DJ mixer	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	291 mm
Height	89 mm
Weight	2400 g
Package depth	305 mm
Package width	370 mm
Package height	190 mm
Package weight	3200 g
