92 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 3 Product Commissioning
Table 16 - Default Consume Assembly for Bulletin 290E/291E
Table 17 - Bulletin 290E/291E Consume Assembly Command Tags
Instance 150 “Starter Cmd” - DeviceLogix Consumed Assembly for Bulletin 290 / 291 Starters
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 ResetFault RunReverse RunForward
1 Out05 Out04 Out03 Out02 Out01 Out00
2 Pt07DeviceIn Pt06DeviceIn Pt05DeviceIn Pt04DeviceIn Pt03DeviceIn Pt02DeviceIn Pt01DeviceIn Pt00DeviceIn
3 Pt15DeviceIn Pt14DeviceIn Pt13DeviceIn Pt12DeviceIn Pt11DeviceIn Pt10DeviceIn Pt09DeviceIn Pt08DeviceIn
4 AnalogDeviceIn (low byte)
5 AnalogDeviceIn (high byte)
Device Name Name Logix Tag Name Data Type Style
DEMO_REV RunForward DEMO_REV:O.RunForward BOOL Decimal
DEMO_REV RunReverse DEMO_REV:O.RunReverse BOOL Decimal
DEMO_REV ResetFault DEMO_REV:O.ResetFault BOOL Decimal
DEMO_REV Pt00Data DEMO_REV:O.Pt00Data BOOL Decimal
DEMO_REV Pt01Data DEMO_REV:O.Pt01Data BOOL Decimal
DEMO_REV Pt02Data DEMO_REV:O.Pt02Data BOOL Decimal
DEMO_REV Pt03Data DEMO_REV:O.Pt03Data BOOL Decimal
DEMO_REV Pt04Data DEMO_REV:O.Pt04Data BOOL Decimal
DEMO_REV Pt05Data DEMO_REV:O.Pt05Data BOOL Decimal
DEMO_REV Pt00DeviceIn DEMO_REV:O.Pt00DeviceIn BOOL Decimal
DEMO_REV Pt01DeviceIn DEMO_REV:O.Pt01DeviceIn BOOL Decimal
DEMO_REV Pt02DeviceIn DEMO_REV:O.Pt02DeviceIn BOOL Decimal
DEMO_REV Pt03DeviceIn DEMO_REV:O.Pt03DeviceIn BOOL Decimal
DEMO_REV Pt04DeviceIn DEMO_REV:O.Pt04DeviceIn BOOL Decimal
DEMO_REV Pt05DeviceIn DEMO_REV:O.Pt05DeviceIn BOOL Decimal
DEMO_REV Pt06DeviceIn DEMO_REV:O.Pt06DeviceIn BOOL Decimal
DEMO_REV Pt07DeviceIn DEMO_REV:O.Pt07DeviceIn BOOL Decimal
DEMO_REV Pt08DeviceIn DEMO_REV:O.Pt08DeviceIn BOOL Decimal
DEMO_REV Pt09DeviceIn DEMO_REV:O.Pt09DeviceIn BOOL Decimal
DEMO_REV Pt10DeviceIn DEMO_REV:O.Pt10DeviceIn BOOL Decimal
DEMO_REV Pt11DeviceIn DEMO_REV:O.Pt11DeviceIn BOOL Decimal
DEMO_REV Pt12DeviceIn DEMO_REV:O.Pt12DeviceIn BOOL Decimal
DEMO_REV Pt13DeviceIn DEMO_REV:O.Pt13DeviceIn BOOL Decimal
DEMO_REV Pt14DeviceIn DEMO_REV:O.Pt14DeviceIn BOOL Decimal
DEMO_REV Pt15DeviceIn DEMO_REV:O.Pt15DeviceIn BOOL Decimal
DEMO_REV Int00DeviceIn DEMO_REV:O.Int00DeviceIn INT Decimal
