Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 93
Product Commissioning Chapter 3
Table 18 - Bulletin 290E/291E Starters Starter Stat Produced Assembly
Table 19 - Bulletin 290E/291E Produced Assembly Status Tags
Instance 152 “Starter Stat” - Produced Assembly for Bulletin 290E / 291E Starters
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Reserved - (name):I.ConnectionFault ➊
1 Reserved - (name):I.ConnectionFault ➊
2 Reserved - (name):I.ConnectionFault ➊
3 Reserved - (name):I.ConnectionFault ➊
4 CurrentFlowing NetControlStatus Ready RunningReverse RunningForward WarningPresent TripPresent
5 DisconnectClosed KeyPadHand KeyPadOff KeyPadAuto DLXEnabled
6 Pt05 Pt04 Pt03 Pt02 Pt01 Pt00
7
8 Pt07DeviceOut Pt06DeviceOut Pt05DeviceOut Pt04DeviceOut Pt03DeviceOut Pt02DeviceOut Pt01DeviceOut Pt00DeviceOut
9 Pt15DeviceOut Pt14DeviceOut Pt13DeviceOut Pt12DeviceOut Pt11DeviceOut Pt10DeviceOut Pt09DeviceOut Pt08DeviceOut
10 AnalogDeviceOut (low byte)
11 AnalogDeviceOut (high byte)
12
Param 1— PhaseL1Current
13
14
Param 2— PhaseL2Current
15
16
Param 3— PhaseL3Current
17
18
Param 4— AverageCurrent
19
20
Param 5—%ThermalUtilized
21
22
Param 11 — SwitchedVolts (OutputSourceV, IPS units)
23
24
Param 12 — UnswitchedVolts (SensorSourceV, IPS units)
25
26
Param 16 — TripStatus
27
28
Param 17 — WarningStatus
29
➊ PLC Communication Fault Only
Device Name Name Logix Tag Name Data Type Style
DEMO_REV Fault DEMO_REV:I.Fault DINT Binary
DEMO_REV TripPresent DEMO_REV:I.TripPresent BOOL Decimal
DEMO_REV WarningPresent DEMO_REV:I.WarningPresent BOOL Decimal
DEMO_REV RunningForward DEMO_REV:I.RunningForward BOOL Decimal
DEMO_REV RunningReverse DEMO_REV:I.RunningReverse BOOL Decimal
DEMO_REV Ready DEMO_REV:I.Ready BOOL Decimal
DEMO_REV CurrentFlowing DEMO_REV:I.CurrentFlowing BOOL Decimal
