Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 19

Digital Module Operation in a Control System Chapter 1

Table 3 describes the module compatibility requirements when you use

Compact 5000 I/O digital modules with Logix 5000 controllers.

Table 3 - Compact 5000 I/O Digital Modules Controller and Software Compatibility Requirements

Modules Location

Controllers

Logix Designer

ApplicationSystem Cat. Nos.

Standard Modules

5069-IA16, 5069-IB16,

5069-IB16F, 5069-

IB16K, 5069-IB6F-3W,

5069-OA16, 5069-OB8,

5069-OB16, 5069-

OB16F, 5069-OB16K,

5069-OW4I, 5069-

OW16, 5069-OX4I

Local I/O modules CompactLogix 5380 5069-L320ER, 5069-L320ERMK, 5069-L330ERMK,

5069-L340ERM, 5069-L350ERMK

Version 28.00.00 or later

5069-L306ER, 5069-L306ERM, 5069-L310ER, 5069-L310ERM,

5069-L310ER-NSE, 5069-L310ERS2, 5069-L320ERM,

5069-L320ERMK, 5069-L330ER, 5069-L330ERM,

5069-L330ERMK, 5069-L340ER

Version 29.00.00 or later

5069-L350ERM, 5069-L350ERMK, 5069-L380ERM,

5069-L3100ERM

Version 30.00.00 or later

CompactLogix 5480 5069-L46ERMW Version 32.00.00 or later

Compact GuardLogix 5380 5069-L306ERS2, 5069-L306ERMS2, 5069-L310ERS2, 5069-

L310ERMS2, 5069-L320ERS2, 5069-L320ERS2K, 5069-

L320ERMS2, 5069-L320ERMS2K, 5069-L330ERS2, 5069-

5069-L330ERS2K, L330ERMS2, 5069-L330ERMS2K, 5069-

L340ERS2, 5069-L340ERMS2, 5069-L350ERS2, 5069-

L350ERS2K, 5069-L350ERMS2, 5069-L350ERMS2K, 5069-

L380ERS2, 5069-L380ERMS2, 5069-L3100ERS2, 5069-

L3100ERMS2

Version 31.00.00 or later

Remote I/O modules CompactLogix 5380 5069-L320ER, 5069-L340ERM Version 28.00.00 or later

5069-L306ER, 5069-L306ERM, 5069-L310ER, 5069-L310ERM,

5069-L310ER-NSE, 5069-L310ERS2, 5069-L320ERM, 5069-

L330ER, 5069-L330ERM, 5069-L340ER

Version 29.00.00 or later

5069-L350ERM, 5069-L380ERM, 5069-L3100ERM Version 30.00.00 or later

CompactLogix 5480 5069-L46ERMW Version 32.00.00 or later

Compact GuardLogix 5380 5069-L306ERS2, 5069-L306ERMS2, 5069-L310ERS2, 5069-

L310ERMS2, 5069-L320ERS2, 5069-L320ERS2K, 5069-

L320ERMS2, 5069-L320ERMS2K, 5069-L330ERS2, 5069-

5069-L330ERS2K, L330ERMS2, 5069-L330ERMS2K, 5069-

L340ERS2, 5069-L340ERMS2, 5069-L350ERS2, 5069-

L350ERS2K, 5069-L350ERMS2, 5069-L350ERMS2K, 5069-

L380ERS2, 5069-L380ERMS2, 5069-L3100ERS2, 5069-

L3100ERMS2

Version 31.00.00 or later

ControlLogix® 5580 1756-L83E, 1756-L85E Version 28.00.00 or later

1756-L81E, 1756-L82E, 1756-L84E Version 29.00.00 or later

GuardLogix 5580 1756-L81ES, 1756-L82ES, 1756-L83ES, 1756-L84ES Version 31.00.00 or later
