Chapter 7 Move/Logical Instructions (MOV, MVM, BTD, MVMT, BTDT, CLR, SWPB, AND, OR, XOR, NOT, BAND, BOR, BXOR, BNOT)
The logical instructions perform operations on bits.
If you want to Use this instruction Available in these languages Page
Copy a value MOV Relay ladder
Structured text
(1)
295
Copy a specific part of an integer MVM Relay ladder 297
Copy a specific part of an integer in function block MVMT Structured text
Function block
300
Move bits within an integer or between integers BTD Relay ladder 303
Move bits within an integer or between integers in
function block
BTDT Structured text
Function block
306
Clear a value CLR Structured text
(1)
Relay ladder
309
Rearrange the bytes of a INT, DINT, or REAL tag SWPB Relay ladder
Structured text
311
(1) There is no equivalent structured text instruction. Use other structured text programming to achieve the same result. See the description for the instruction.
If you want to Use this instruction Available in these languages Page
Bitwise AND Operation Bitwise AND
&
(1)
Relay ladder
Structured text
(2)
Function block
315
Bitwise OR operation Bitwise OR Relay ladder
Structured text
(2)
Function block
319
Bitwise, exclusive OR operation Bitwise XOR Relay ladder
Structured text
(2)
Function block
323
Bitwise NOT operation Bitwise NOT Relay ladder
Structured text
(2)
Function block
327
Logically AND as many as eight boolean inputs. Boolean AND (BAND) Structured text
(2)
Function block
331
Logically OR as many as eight boolean inputs. Boolean OR (BOR) Structured text
(2)
Function block
334
Perform an exclusive OR on two boolean inputs. Boolean Exclusive OR (BXOR) Structured text
(2)
Function block
337
Complement a boolean input. Boolean NOT (BNOT) Structured text
(2)
Function block
340
(1) Structured text only.
(2) In structured text, the AND, OR, XOR, and NOT operations can be bitwise or logical.
