Rockwell Automation Publication 1756-RM003N-EN-P - October 2011 449
Chapter
11
Program Control Instructions
(JMP, LBL, JSR, RET, SBR, JXR, TND, MCR, UID, UIE, AFI, NOP, EOT,
SFP, SFR, EVENT)
Use the program control instructions to change the flow of logic.
Topic Page
Jump to Label (JMP) Label (LBL) 451
Jump to Subroutine (JSR) Subroutine (SBR)
Return (RET)
453
Jump to External Routine (JXR) 462
Temporary End (TND) 465
Master Control Reset (MCR) 467
User Interrupt Disable (UID) User Interrupt
Enable (UIE)
470
Always False Instruction (AFI) 472
No Operation (NOP) 473
End of Transition (EOT) 474
SFC Pause (SFP) 476
SFC Reset (SFR) 478
Trigger Event Task (EVENT) 481
