C-34 1734-POINT I/O Module/RSLogix 5000 Controller Tag Reference
1734-SSI
1 Channel Synchronous Serial Interface
Configuration Data Data Type Default
Value
Valid Data Values
Run SINT 1 0=Module Not Running
1=Module Is Running
Gray Binary SINT 1 0=Binary Code
1=Gray Code
Word Length SINT 13 2 to 31
Data Speed SINT 5 5=125K Baud
6=250K Baud
7=500K Baud
8=1M Baud
9=2M Baud
G2B Convert (Gray to Binary) SINT 0 0=No Convert
1=Convert
Standardization
(Divide / Shift using Trailing)
SINT 0 0=No Standardization
1=Apply Standardization
SSI Word Delay Time INT 64 -32,768 to 32,767 µs
(16 - 65,535)
Trailing (No. of Trailing Bits) SINT 0 0 to 16
Input Latch Control
InputLatch_0
InputLatch_1
SINT
BIT 0
BIT 1
0 00=Off
01=Falling Edge of Input
10=Rising Edge of Input
11=Both Edges of Input
Sensor Resolution
(Positions per Rev. or Stroke)
INT 1 -32,768 to 32,767 counts
(1 - 65,535)
Sensor Cycle
(Total Revolutions or Strokes)
INT 1 -32,768 to 32,767 counts
(1 - 65,535)
Compare 0 Value DINT 0 -2,147,483,648 to
2,147,483,647
(0 - 4,294,967,295)
Compare 1 Value DINT 0 -2,147,483,648 to
2,147,483,647
(0 - 4,294,967,295)
Compare 0 Control
Compare0_0
Compare0_1
SINT
BIT 0
BIT 1
0 00=Off
01=Up Direction
10=Down Direction
11=Both Directions
Compare 1 Control;
Compare1_0
Compare1_1
SINT
BIT 0
BIT 1
0 00=Off
01=Up Direction
10=Down Direction
11=Both Directions
