1 Publication 1734-UM011A-EN-P - February 2004
Chapter
5
Configure the 1734-AENT for Direct
Connection and Rack Optimization
in RSLogix 5000
What’s in This Chapter
This chapter guides you through the steps required to configure your 1734
POINT I/O Ethernet Adapter for both direct connection and rack
optimization using RSLogix 5000. You can mix communication formats for
different I/O modules communicating through the same adapter. I/O
modules set up to use rack optimization will communicate at the rate of the
RPI configured for the 1734-AENT adapter. I/O modules configured for
direct communication will communicate at their own set RPIs and ignore the
1734-AENT adapter’s RPI. Note that the modules presented in this chapter
are configured using RSLogix 5000, version 11. The chapter contains the
following main sections:
What you will do See page
Set Up the Hardware 5-2
Create the Example Application 5-3
Configure the I/O 5-4
Add the Local EtherNet/IP Bridge to the I/O Configuration 5-4
Add the POINT I/O Adapter to the I/O Configuration 5-6
Add the POINT I/O Module and Configure For Direct Connection 5-8
Add the POINT I/O Module and Configure For Rack Optimization 5-11
Download the Program to the Controller 5-12
Verify the Module Chassis Size 5-13
Access Module Data via the 1734-AENT Adapter 5--16
ATTENTION
You must use Series C POINT I/O modules with the
1734-AENT adapter. Series A or B POINT I/O
modules will not work with this adapter.
