1 Publication 1734-UM011A-EN-P - February 2004
Appendix
D
1734-AENT Quick Start
What’s In This Appendix?
In this quick start, you will learn how to use the 1734-AENT with a
ControlLogix processor for EtherNet/IP.
Necessary Pre-requisites
Before you began this quick start, make sure the following conditions are in
place.
• The ControlLogix Controller and the RSLogix software version must be
version 11 or higher.
• The 1756-ENBT module must be version 2.3 or higher.
• The 1734 POINT I/O modules must be Series C (except for the
1734-232ASC modules, which can be Series A).
• The recommended RPIs are being used: Discrete = 10 ms or higher,
Analog and Specialty = 50 ms or higher.
• The 1734-AENT POINT I/O adapter is a child to a local 1756-ENBT
module.
IMPORTANT
This quick start contains a simple set of steps and
reminders that will help you avoid errors when you are
configuring your POINT I/O system for EtherNet/IP.
ATTENTION
You must use Series C POINT I/O modules with the
1734-AENT adapter. Series A or B POINT I/O
modules will not work with this adapter.
