Publication 1734-UM011A-EN-P - February 2004
C-2 1734-POINT I/O Module/RSLogix 5000 Controller Tag Reference
Note that all POINT I/O modules must be Series C or above for
RSLogix5000 V.11 compatibility.
The 1734-232ASC/A (Series A) is presently the only exception to the Series C
requirement. It can be used in RSLogix 5000 V.11 with a Generic Profile, OR
it can be used in RSLogix 5000 V.12 with a Thin Profile.
Valid Number Ranges for
RSLogix 5000 Data Types
Accepted parameter values are dependent on POINT I/O Module type and
Tag type.
1734 POINT I/O
Catalog Number
RSLogix5000 Module Description
Specialty I/O
1734-232ASC/C 1 Channel ASCII Interface Module
1734-IJ/C 1 Channel 5V DC Encoder/Counter
1734-IK/C 1 Channel 15-24V DC Encoder/Counter
1734-SSI/C 1 Channel Synchronous Serial Interface
1734-VHSC24/C 1 Channel 15-24V DC Very High Speed Counter
1734-VHSC5/C 1 Channel 5V DC Very High Speed Counter
Type Number of Bits Range
BIT 1 Bit 0 or 1
SINT 8 Bit -128 to +127
INT 16 Bit -32,768 to 32,767
DINT 32 Bit -2,147,483,648 to 2,147,483,647
