The Rockwell Software RSLinx Gateway - [RSWho - 1] screen appears.
TIP
The RSWho screen is actually RSLinx’s network browser
interface, which lets you view all of your active network
connections.
The left pane of this display is the Tree Control, which
shows networks and devices in a hierarchical view. When a
network or device is collapsed, as indicated by the + sign,
you can click on the + sign or double click on the network
or device icon to expand the view and begin browsing.
When a network or device is expanded, as indicated by the
- sign, you can click on the - sign or double click on the
network or device icon to collapse the view. The right pane
of the RSWho display is the List Control, which is a
graphical representation of all of the devices present on the
network.
TIP
If there is a communication status error with a device (e.g.,
when a recognized device is inadvertently unplugged), that
device appears with a red X, indicating that RSWho
previously recognized it, but now it can not. You can
choose to remove the device from the RSWho display, or
you can choose to correct the communication error.
