(H)
Supply 3: Is there
12VDC between H4-1
and H4-8?
(H)
Supply 4: Is there
12VDC between H4-1
and H4-7?
Yes
Replace AP4b.
No
(H)
Supply 5: Is there
12VDC between H4-1
and H4-6?
Yes
Replace AP4b.
No
(H)
Supply 6: Is there
12VDC between H4-1
and H4-5?
Yes
Replace AP4b.
No
(H)
Supply 7: Is there
12VDC between H4-1
and H4-4?
Yes
Replace AP4b.
No
(H)
Supply 8: Is there
12VDC between H4-1
and H4-3?
Yes
Replace AP4b.
No
Check the soap vendor
equipment or contact
your soap vendor.
Yes
Replace AP4b.
No
Troubleshooting
©
