Frame Balance Switch Error E FbAL
(A)
Is there 24VDC
between H7-9 and
H7-10?
Replace AP1.
No
(B)
Frame balance Jumper
is open. Inspect
jumper and connection
to AP1.
Repair/replace wiring
if necessary.
Yes
Troubleshooting
©
